ABB PSTB370-600-70 softstarter: Selection Checks for 208-600 V Motor Applications

The ABB PSTB370-600-70 softstarter is a 370 A unit in ABB's PST(B) softstarter family. It is designed to control motor starting and stopping by reducing the electrical and mechanical stress associated with direct-on-line starting. The model designation identifies a 208-600 V main-circuit range and a 100-250 V AC control supply.

The letter B indicates an integrated bypass contactor. Once the motor reaches full speed, the bypass reduces losses across the power semiconductors and limits heat generation inside the panel. This makes the model relevant to large pumps, fans, compressors, conveyors and other industrial motor loads when the starting duty has been checked correctly.

Reference image: the supplied photograph shows ABB low-voltage product packaging and does not show the PSTB370-600-70 softstarter itself. It is included as a brand and stock-packaging reference only. Buyers should request an actual product and nameplate photograph when confirming an exact replacement.

Confirmed model data

The ratings above describe the ABB model and referenced selection data. Final motor suitability still depends on load characteristics, starting time, starts per hour, ambient temperature, altitude and the chosen in-line or inside-delta connection. A 370 A nameplate rating alone is not enough to approve an application without checking the motor and duty cycle.

How the PSTB softstarter supports motor operation

During acceleration, the softstarter controls the voltage applied to the motor so current and torque rise more gradually than with a direct-on-line start. This can reduce voltage dips, coupling shock and mechanical wear. The selected ramp, initial voltage, current limit and torque-control settings should match the driven machine rather than being copied blindly from another installation.

For pump applications, a controlled stop may reduce pressure transients in suitable systems. For fans and conveyors, smooth acceleration can reduce belt slip and drivetrain stress. A softstarter does not provide continuous speed regulation like a variable-frequency drive, so buyers should first decide whether the application needs controlled starting only or adjustable operating speed.

Typical applications for ABB PSTB370-600-70

• Centrifugal pumps where a controlled start and stop can reduce mechanical and hydraulic stress
• Fans and blowers requiring lower starting current and smoother acceleration
• Conveyors where torque ramping can reduce shocks to belts, couplings and transported material
• Compressors and industrial machines with a verified normal or heavy starting profile
• Retrofit projects replacing an installed ABB PSTB unit with matching electrical and mechanical requirements

Protection and control questions to review

ABB's PST(B) platform combines motor and load protection functions with operational warnings. When replacing an existing unit, record the active protection settings and event history before removal. Confirm overload class, current limit, underload or locked-rotor supervision, phase-related protection and any external motor sensor arrangement used by the project.

The softstarter must be coordinated with appropriate short-circuit protection, isolation equipment and panel design. Cable size, busbar connection, earthing, enclosure temperature and ventilation should be reviewed against ABB instructions and applicable standards. The built-in bypass does not remove the need for correct upstream protection or a suitable emergency isolation strategy.

Communication and commissioning considerations

The PST(B) range can communicate through compatible ABB FieldBusPlug accessories. For a replacement, identify the existing network, plug type, control words and PLC logic before ordering. A mechanically compatible softstarter may still require engineering changes if the communication interface or parameter mapping differs from the existing installation.

Commissioning records should include motor current, start time, stop mode, current limit, ramp settings and actual application behavior. After installation, observe several starts under normal load and check for excessive acceleration time, unstable torque, abnormal heating or unexpected protection trips.

Replacement and lifecycle review

PSTB370-600-70 belongs to ABB's established PST(B) range, while newer projects may also consider the PSTX platform. A newer family should not be assumed to be a direct drop-in replacement. Compare cabinet space, terminals, current rating, bypass design, control voltage, I/O, communication, protection functions and parameter conversion before approving a migration.

For an exact ABB PSTB370-600-70 softstarter spare, preserve the full model and product ID in the inquiry. Ask for condition, revision, actual label photos, included accessories and documentation. This is especially important when a unit is intended for an existing MCC where cable locations and control interfaces are already fixed.

RFQ checklist

1. Complete model PSTB370-600-70 and ABB product ID 1SFA894015R7000
2. Motor rated voltage, full-load current, power, frequency and efficiency class
3. Application type, load torque, acceleration time, starts per hour and ambient temperature
4. In-line or inside-delta connection and the required current setting range
5. Control voltage, start/stop control arrangement and fieldbus communication requirement
6. Panel dimensions, ventilation, short-circuit protection and upstream isolation details
7. Quantity, destination country, required delivery date and document requirements

Request a model-specific quotation

Send HKXYTECH the keyword ABB PSTB370-600-70 softstarter together with the complete motor and application data. A model-specific review can then confirm the requested ABB product number, electrical rating, supply condition, available documentation and delivery terms without confusing PSTB370 with PSE370 or PSTX370 units that use different product numbers and feature sets.
