Hirschmann BRS30-1604OOOO-TTDY99HHSEAXX.X.XX Twenty-Port EEC-2A Configuration Review for Metal-Housing Networks with Copper Devices and SFP Uplinks
Hirschmann BRS30-1604OOOO-TTDY99HHSEAXX.X.XX is the BRS30-16TX/4SFP-EEC-2A configuration in the Hirschmann BOBCAT range. This EEC-2A selection brings together a metal housing, an extended temperature range and the specific 2A order configuration. The physical network comprises sixteen Fast Ethernet copper ports and four 100/1000 Mbit/s SFP slots; both hardware identity and the separately chosen optics belong in the purchasing record.
Reference photograph: shared Hirschmann product image. The photographed unit may be a different model; this image does not establish the configuration or availability of Hirschmann BRS30-1604OOOO-TTDY99HHSEAXX.X.XX.
Three identities to keep together
- Retain the complete EEC-2A product code, the shorter Type and the numeric part number on the purchase request.
- Compare the delivered software and required functions against the accepted specification; do not reduce the 2A option to an assumed label meaning.
- Record supported SFP module models separately so the switch configuration and the optical bill of materials remain unambiguous.
Catalog configuration
| Brand / series | Hirschmann / BOBCAT |
| Type | BRS30-16TX/4SFP-EEC-2A |
| Product code | BRS30-1604OOOO-TTDY99HHSEAXX.X.XX |
| Part number | 942170118 |
| Port Type and Quantity | 16 × 10/100BASE-TX RJ45; 4 × 100/1000 Mbit/s SFP slots |
| Operating Voltage | 2 x 12 VDC ... 24 VDC |
| Power Consumption | 15 W |
| Operating temperature | -40 to +70 °C |
| Dimensions (WxHxD) | 123 mm x 140 mm x 115 mm |
| Housing | Metal |
| Mount Type | DIN Rail |
| IP Protection Rating | IP30 |
A metal enclosure changes the installation review
Use the dimensions listed for this EEC configuration when checking the DIN rail layout. Allow access for supply terminals, RJ45 plugs and removable optics. The IP30 housing rating should be considered with the surrounding cabinet protection; a metal enclosure by itself does not establish outdoor or washdown suitability.
What remains to be checked for an optical uplink?
Select compatible 100/1000 Mbit/s SFPs for the required fiber and remote partner, then check their operating temperature and link budget. The EEC switch rating and the module rating are separate. Also identify whether modules, patch leads and configuration services are included in the requested supply scope.
Keep EEC-2A and optical requirements visible
Provide HKXY with the full ordering reference, quantity, destination and project software requirements. Include the module schedule and any cabinet drawing constraints so the quotation can clearly distinguish the requested device from accessories and optional services. Quote reference: Hirschmann BRS30-1604OOOO-TTDY99HHSEAXX.X.XX; Type BRS30-16TX/4SFP-EEC-2A; part 942170118.
Technical source: Belden configuration record for BRS30-16TX/4SFP-EEC-2A. Check the current manufacturer documentation and delivered revision before final engineering approval.
